Blood Gas System
GASTAT-700Model
Evolution in blood gas analysis towards new stage
Innovative proposal by TMC
24 hours, 365 days connected to smart phone / PC
●Reliable and accurate results
●Super Long Glc/Lac electrode shelf life; Low running cost due to 3 months shelflife Glc/Lac electrode
●Maintenance reservation, remote monitoring by Internet of Things
Sample Type | Whole blood, Serum, Plasma, Dialysate | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Test available and measured range |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Sample volume | GASTAT-710/720(aqc);Syringe: 195μL / Capillary: 80μL / Micro mode: 40μL GASTAT-730/735(aqc);Syringe: 195μL / Capillary: 100μL / Micro mode: 40μL |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Analysis time | From pressing analysis icon to test result display (Ideal value) GASTAT-710/720(aqc);About 60 seconds GASTAT-730(aqc);About 70 seconds GASTAT-735(aqc);About 90 seconds |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display | 12 inch full color display / Touch panel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Entered parameter | Patient ID, Patient Temp, Sample type, FiO2, Height, Weight, Sex, Age | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Calibration | Automatic, programmable 1 and 2 point calibration | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Reagent and waste detection | Automatic intergrated detection | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Data storage | 10,000 sample | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Printer | Line thermal printer | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interface | TCP/IP (IHE compatible) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Barcode reader | Built-in (12type of barcode available) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating temperature | 10〜30℃ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Humidity | 20〜80% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power | AC85~264V 50/60Hz 240W Back up option by battery | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions (mm) | 400(W)X575(D)X635(H) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Weight | 28KG | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Others | Maintenance reservation/Information report/Remote management/Network/Animation guidance |
