RFID Process Control System
u-TRIPS
By using RFID specimen label, scanner and management software, the system enables real-time tracking and management of urine specimen in remote place.
Japan Market Only
●Enables specimen management from the beginning to the end of urine test workflow.
●Enables specimen tracking operating with Assist Solution Software.
| Item | Specification/Feature |
|---|---|
| The number of urine cup readable at once time | 8 cups (32 labels) ※under the condition of TMC rack and RFID labels. |
| Required state of objects while scanning | Stationary state ※under the condition of TMC rack and RFID labels. |
| Reader/interrogator ※At designated access point | UHF band RW module |
| Application | Client ●Urine cup monitor application ●Monitor display ●Identification between urine cup and tube ●Search |
| Frequency | 915-928MHz (UHF band) |
| RFID tag | Memory EPC: -96 bit Compatible to EPCglobal UHF Gen 2 (ISO/IEC18000-6 Type C) |
| External communication | Socket communication |
| Operation PC | OS Windows7 Professional (32bit) CPU Intel® Atom™ Processor Z670 (HT Technology) Main memory: 2GB or more Display resolution: 1280*800 dot or more: Memory Disk: (HD/SSD) Disk space should be 30GB or more. Audio: MIDI USB: 2 or more USB port. |
| Dimension | Reader/interrogator: W190*D200*H65mm RFID Scanner: W240*D290*H85mm |
| Weight | Reader/interrogator: Approximately 3 KG RFID Scanner: 3.5 KG |
※Sensitivity varies depending on operating environment.
※In case of using a plural number of RFID devices at one place, Interference might happen.
